Technical specifications for SGDV-3R5D11A020000
Yaskawa SGDV-3R5D11A020000 Sigma-5 Servo Drive
The Yaskawa SGDV-3R5D11A020000 is a high-performance Sigma-5 series servo drive, engineered for fast, precise motion control in a wide range of industrial automation applications. It supports both AC and DC input, making it highly versatile for different installation environments.
On the input side, the drive accepts 3-phase AC power at 380-480 VAC, drawing up to 2.5 Amps at 50/60 Hz. Additionally, it features a DC input of 24 VDC at 1.2 Amps, allowing for added flexibility in power configuration. On the output side, the drive delivers 3-phase power at 3.5 Amps, with an output range of 0-480 VAC and 0-300 Hz, capable of supporting 1 kW motors.
This servo drive is built for reliable performance and fast response, essential in applications requiring precision, such as robotics, CNC machinery, and packaging systems. The unit weighs 2.72 kgs, making it compact and easy to install in various control cabinets or enclosures.
Factory warranty may not apply, but Anadi Automation provides a 1-year warranty, giving added assurance of support and reliability.
The SGDV-3R5D11A020000 combines power, flexibility, and the trusted performance of Yaskawa’s Sigma-5 technology—making it an ideal solution for modern motion control systems.
