Technical specifications for
S3030-1-NA-SB
Kollmorgen S30301-NA Digital Servo Amplifier
The S30301-NA is a high-performance digital servo amplifier from Kollmorgen’s SERVOSTAR S300 series, designed to provide precise control in demanding industrial automation applications. It supports a current rating of 3 A RMS and operates within a wide voltage range of 208 to 480 V AC, delivering reliable power with an input power rating of 1.2 kVA.
This amplifier features an inductance of 8.5 mH and supports continuous power regeneration up to 20 W, enhancing energy efficiency during operation. Built to withstand industrial environments, it has an IP20 enclosure protection rating, safeguarding it from dust and solid objects. The device operates effectively within a temperature range of 0°C to 70°C, and meets Overvoltage Category III standards as per European regulations, ensuring robust safety and durability.
Equipped with 4 programmable digital inputs and 2 programmable analog inputs, the S30301-NA offers flexible interfacing options for various control requirements. Its compact design measures 70 mm in width, 270 mm in height, and 171 mm in depth, with a total weight of approximately 2.7 kg, making it suitable for diverse industrial installations.
