Technical specifications for
1762-L40BXBR
Allen-Bradley 1762-L40BXBR Programmable Controller Technical Specifications
The 1762-L40BXBR is a Programmable Logic Controller (PLC) from the Allen-Bradley MicroLogix 1200 series. Below are the detailed technical specifications for this model:
1. General Specifications
- Manufacturer: Rockwell Automation
- Part Number / Catalog No.: 1762-L40BXBR
- Brand: Allen-Bradley
- Series: MicroLogix 1200
- Product Type: Programmable Controller
2. Power Specifications
- Power Supply: 24V DC
- Power Supply Usage: 82 VA
- Power Consumption: 40 Watts
- Power Supply Inrush Current:
- 120V AC: 25A for 8 ms
- 240V AC: 40A for 4 ms
- Output Currents:
- 600mA at 5 Volts DC
- **500mA at 24 Volts DC
- Heat Dissipation: 27.9 Watts
3. Input Specifications
- Number of Inputs:
- 20 x 24V DC
- 4 x Fast 24V DC
- Input Circuit Type: 24 VDC
- Inrush Input Currents: 150A at 30 seconds
4. Output Specifications
- Number of Outputs:
- 8 x Relay Outputs
- 7 x 24V DC FET Outputs
- 1 x High-Speed 24V DC FET Output
- Output Circuit Type: Relay; FET
- Relay Contact Rating:
- 24-125V DC
- 120-240V AC
- Mechanical Cycles: 20,000,000
- Load Current: 10A, minimum
5. Communication Ports and Protocols
- Communication Ports:
- One (1) 8-Pin mini-DIN serial port
- One (1) Programming port
- Supported Protocols:
- DF1
- DH-485
- ASCII
- MODBUS
6. Environmental Specifications
- Operating Temperature: 0 to 55 degrees Celsius (32 to 131°F)
- Operating Shock: 30 G
- Vibration: 5G at 10 to 500 Hertz
7. Dimensions
- Height: 90 mm (104 mm with DIN latch open)
- Width: 160 mm
- Depth: 87 mm
8. Shipping and Weight
- Shipping Weight: 2.4 pounds (1.1 kg)
