Technical specifications for CS1H-CPU65H
Omron CS1H-CPU65H Programmable Logic Controller (PLC)
The Omron CS1H-CPU65H is a high-performance Programmable Logic Controller (PLC) CPU unit from the CS1 series, tailored for large-scale and complex industrial automation systems. This CPU model is renowned for its high-speed processing and large memory capacity, making it ideal for sophisticated control applications.
The program capacity is 60K steps, allowing the storage and execution of extensive programs. It supports a data area memory capacity of 128 kWords, which includes DM: 32 kWords and EM: 32 kWords x 3 banks, providing ample space for variable storage and advanced control strategies.
One of the most impressive features of this model is its LD instruction processing speed of just 0.02 μs, enabling ultra-fast response and real-time processing. The CPU supports up to 5,120 I/O bits and can be expanded with up to 7 Expansion Racks, offering excellent scalability for growing systems.
For connectivity, the unit includes built-in Peripheral and RS-232C ports, and it is compatible with various optional boards, such as Memory Cards, Serial Communication Boards, and Loop Control Boards, enhancing its flexibility and communication capabilities.
The control method is a stored program, and it uses a cyclic scan and immediate processing I/O control method, which ensures predictable and efficient execution. Programming is done using ladder diagrams, a widely used language in industrial automation for ease of development and debugging.
The CPU operates with a maximum current consumption of 150 mA at 5 V DC, making it energy efficient despite its powerful capabilities. With basic instruction execution times as low as 0.02 μs and special instructions at 0.04 μs, the CS1H-CPU65H stands out as a reliable and high-speed PLC solution for demanding industrial environments.
