Technical specifications for
FX2N-5A
Mitsubishi FX2N-5A – 4-Channel Analog Input & 1-Channel Output Module for MELSEC-F PLCs
The Mitsubishi FX2N-5A is a versatile and compact analog I/O module designed to extend the functionality of MELSEC-F series PLCs. Offering four analog input channels and one analog output channel, this module is tailored for precise signal processing in a wide range of industrial control and automation applications.
Designed and manufactured by Mitsubishi Electric, the FX2N-5A integrates seamlessly with FX2N and other compatible MELSEC-F series PLC systems, delivering robust analog input and output capabilities within a compact footprint. It is ideal for applications where real-time monitoring and control of voltage or current signals are required, such as temperature regulation, pressure monitoring, flow control, and more.
The FX2N-5A supports various input ranges to accommodate different sensor outputs. The four analog inputs can accept both voltage signals (-10V to +10V, -0.1V to +0.1V) and current signals (-20mA to +20mA, 4-20mA), offering flexibility for integration with a wide array of analog devices. Meanwhile, the single analog output channel provides both voltage output (-10V to +10V) and current output (0-20mA, 4-20mA), enabling precise signal delivery to actuators, control valves, and external analog devices.
Operating on a 24V DC power supply, the FX2N-5A occupies 8 I/O points on the PLC, making it a space-saving and efficient addition to control panels. With its DIN rail or panel mountable design, it simplifies installation and integration into existing systems.
This module is built to withstand standard industrial conditions, with an operating temperature range of 0°C to 55°C. The compact design (55 mm wide, 90 mm high, and 87 mm deep) and lightweight structure (0.3 kg) allow for ease of handling and installation, even in tightly packed control cabinets.
The Mitsubishi FX2N-5A is an excellent choice for system integrators, OEMs, and end users seeking a reliable analog interface for their MELSEC-F PLC systems. Whether you're automating a production line, building a custom control panel, or upgrading an existing system, this analog I/O module offers the accuracy, compatibility, and quality expected from Mitsubishi Electric.
