B & R X20DC1196 OUTPUT MODULE

B&R X20DC1196 – Incremental Encoder Input Module for X20 Series with Dual Additional Inputs

The B&R X20DC1196 is a high-precision incremental encoder input module designed for seamless integration within the X20 Series of modular automation components. Tailored to meet the needs of modern industrial motion control and feedback systems, this compact and reliable I/O module provides the essential interfaces required for connecting and monitoring incremental encoders in high-performance environments.

Engineered by B&R Industrial Automation, the X20DC1196 features one ABR incremental encoder input operating at 5V, making it suitable for precise position, speed, and direction feedback in automated systems. This is particularly useful in applications like robotics, CNC machinery, material handling equipment, and packaging systems—anywhere that accurate motion tracking is essential.

In addition to the primary encoder input, the module also provides two additional digital inputs, enhancing its flexibility for monitoring supplementary signals such as limit switches, reference marks, or machine status indicators. These inputs operate at 5/24 VDC, giving engineers the option to interface with various signal types depending on application requirements.

The X20DC1196 also supplies 5/24 VDC and GND specifically for encoder power, simplifying wiring and ensuring consistent performance without the need for external encoder power supplies. This integration streamlines installation while maintaining a compact form factor and clear connection architecture.

Physically, the module weighs only 0.02 kg, which contributes to minimal load on DIN rails and control panel real estate. Like all modules in the B&R X20 series, the X20DC1196 supports efficient modular assembly, allowing for easy configuration and expansion of automation systems with minimal space requirements.

While the factory warranty may not apply, Anadi Automation provides an inclusive 1-year warranty, giving you peace of mind and dependable post-sale support for replacement or refurbished units.

In terms of categorization, this module falls under Sensors > Encoders > Encoders & Resolvers, reflecting its core function as a key interface for incremental motion feedback. Its precision, durability, and compatibility with B&R's renowned automation architecture make it a preferred choice for engineers and integrators working with motion control systems that demand accuracy and reliability.

In summary, the B&R X20DC1196 encoder input module is a dependable and highly efficient component for real-time feedback in industrial automation. Its encoder compatibility, additional inputs, and integrated power supply make it a versatile solution for a wide range of encoder-based applications.
