Technical specifications for 5069-IB16
Allen-Bradley 5069-IB16 Compact 5000 Discrete input module.
The 5069-IB16 is a high-performance digital DC input module from the Compact 5000 I/O series by Rockwell Automation, branded under Allen-Bradley. The 5069 ib16 offers sixteen (16) sinking input channels in one group, designed to support applications requiring 12/24 VDC input voltage with an operating range of 10-32 VDC. With electronic module keying and a rapid input delay time of 50 µs + filter time, this module ensures accurate and efficient signal processing.
The allen bradley 5069 ib16 module features maximum power dissipation of 3.9 Watts and thermal dissipation of 13.3 BTU/hr, making it suitable for continuous operation in industrial environments. It draws MOD power at 75 mA @ 18–32V DC and allows MOD power passthrough up to 9.55 A. It also supports SA power at 200 mA @ 79–264V AC, with a SA power passthrough limit of 9.95 A, offering flexibility in system configurations.
The ab 5069 ib16 comes in an open-style enclosure, with a compact footprint of 5.4 x 0.87 x 4.2 inches and weighs only 0.39 lbs (175 g). It supports removable terminal blocks, including the 5069-RTB18-SPRING RTB and 5069-RTB18-SCREW RTB, for convenient wiring and maintenance. If you're seeking a reliable and scalable solution for digital input needs, the 5069 ib16 allen bradley module, also referred to as 5069ib16, is a top choice in modern automation systems.
