Technical specifications for
2080-LC30-24QWB
Allen-Bradley 2080-LC30-24QWB – Micro 830 PLC
Overview
The Allen-Bradley 2080-LC30-24QWB is a Micro 830 series PLC, designed for small to medium automation applications. It features 14 integrated digital inputs and 10 relay outputs, providing flexible control solutions. This PLC supports Modbus RTU, ASCII, and CIP protocols, making it ideal for industrial automation, motion control, and process management.
Technical Specifications
✅ Manufacturer: Rockwell Automation
✅ Brand: Allen-Bradley
✅ Series: Micro 830
✅ Product Type: Programmable Logic Controller (PLC)
✅ Part Number: 2080-LC30-24QWB
✅ Product Description: Micro 830 PLC with relay outputs
✅ Integrated Digital Inputs: 14 (24V DC/AC)
✅ Integrated Relay Outputs: 10
✅ Motion Axis: Not Available
✅ High-Speed Counters (HSC): 4
✅ Integrated Analog Inputs: None
✅ Integrated Analog Outputs: None
✅ Maximum Digital I/O Capacity: 48
✅ Plug-In Slots: 3
Communication & Networking
✅ Built-in Communication Interfaces:
-
USB 2.0 (for programming and diagnostics)
-
RS232/RS485 Combo Port
✅ Base Serial Port: RS-232/485 (Non-Isolated)
✅ Supported Communication Protocols:
-
Modbus RTU Master/Slave
-
ASCII
-
CIP (Common Industrial Protocol)
Performance & Programming
✅ Maximum Program Steps: 4K Steps
✅ Maximum Data Size: 8K Bytes
✅ Floating Point Math: Supported
✅ PID Control: Supported
✅ User-Defined Function Blocks: Supported
Physical & Environmental Specifications
✅ Dimensions (H x W x D): 90 x 145 x 80 mm
✅ Mounting: DIN Rail or Panel Mounting
✅ Power Supply: 24V DC
Key Features
✔ Compact and Powerful – Ideal for small-scale industrial automation.
✔ Relay Outputs – Supports direct connection to field devices.
✔ Flexible I/O Expansion – Up to 48 digital I/O points with expansion modules.
✔ Multiple Communication Options – USB, RS-232, and RS-485 ports for integration.
✔ PID and Floating Point Math Support – Suitable for process control applications.
✔ Modular Design with Plug-In Slots – Expandable functionality with plug-in modules.
