Technical specifications for
A5E00714562
The SIEMENS FS450R12KE3-S1 IGBT module is a high-power semiconductor device designed for demanding industrial and power control applications. It operates with a maximum collector-emitter voltage of 1200 V and a continuous collector current of 450 A, making it suitable for high-voltage and high-current environments. The module supports a gate-emitter voltage of ±20 V and features a typical collector-emitter saturation voltage of around 1.7 V, ensuring efficient switching performance with reduced power losses. It also includes a forward voltage of approximately 1.65 V, contributing to overall energy efficiency.
Built using advanced IGBT3 technology, the module is configured in a six-pack topology, which is ideal for three-phase inverter systems. It comes in an EconoPACK™ + B package with a robust baseplate design, allowing secure screw mounting and effective heat dissipation. The optimized thermal performance enhances reliability and extends operational life in continuous-duty applications. Additionally, the module integrates emitter-controlled diodes that improve switching behavior and reduce losses during operation.
The FS450R12KE3-S1 is an industrial-grade component that complies with RoHS standards and is widely used in motor drives, UPS systems, renewable energy systems, and heavy automation equipment. Although it is now considered discontinued for new designs, it remains a reliable choice for maintenance, replacement, and legacy system support where consistent performance and durability are required.
