SIEMENS 6SL3210-5DE16-0UA0 SERVO DRIVE

Siemens 6SL3210-5DE16-0UA0 – SINAMICS G120 Power Module PM240-2 for Reliable and Efficient Motor Control

The Siemens 6SL3210-5DE16-0UA0 is a premium PM240-2 Power Module that belongs to the modular SINAMICS G120 drive system, a renowned series developed for precision motor control across a wide range of industrial applications. Engineered for flexibility, efficiency, and performance, this power module serves as a vital component in vector-controlled drive systems, particularly for tasks that demand consistent torque and dynamic operation such as conveyors, compressors, pumps, and fans.

With a rated output power of approximately 7.5 kW (10 HP), the module provides substantial drive capability while maintaining compact dimensions. It accepts a 3-phase AC input voltage of 380 to 480 V ±10% and operates at a frequency range of 47–63 Hz on the input side, while supporting an output frequency up to 650 Hz, making it suitable for variable-speed motor control. The output current is rated around 16 A, although exact values depend on the specific motor and load conditions.

The PM240-2 is equipped with an integrated braking chopper, which allows for efficient energy dissipation during deceleration, particularly useful in applications involving high-inertia loads or rapid stopping requirements. Additionally, it features internal air cooling via a built-in fan, ensuring thermal stability under continuous operation.

From an installation standpoint, the 6SL3210-5DE16-0UA0 is IP20 rated, making it ideal for controlled environments or when mounted inside protective electrical cabinets. The module supports both wall-mounted and cabinet installations, offering flexibility in system integration. Its compact design—measuring approximately 180 mm x 290 mm x 170 mm and weighing around 5 to 6 kg—helps minimize space consumption within control panels.

This model finds widespread application in industrial environments, especially in HVAC systems, conveyor operations, packaging machinery, pumps, and fans, where consistent torque and optimized energy consumption are critical. It is particularly well-suited for machine tool applications and general-purpose automation where scalability, modularity, and communication flexibility are key requirements.

Regarding environmental performance, the power module operates reliably in ambient temperatures ranging from -10°C to +50°C, with derating above certain thresholds. It tolerates storage temperatures as low as -40°C and as high as +70°C, and is capable of functioning in high-humidity environments, tolerating up to 95% relative humidity (non-condensing).

Overall, the Siemens 6SL3210-5DE16-0UA0 PM240-2 module is a robust, high-performance solution that ensures precise motor control while offering safety, expandability, and ease of maintenance—making it a dependable choice for modern industrial drive systems. At Anadi Automation, we provide professional-grade automation components with dependable service and support to meet the most demanding control system needs.
