SIEMENS 6SL3210-5DE12-4UA0 SERVO DRIVE

Siemens 6SL3210-5DE12-4UA0 – SINAMICS G120 PM240-2 Power Module for 1.1 kW Motor Control

The Siemens 6SL3210-5DE12-4UA0 is a compact and efficient Power Module PM240-2, part of the SINAMICS G120 modular drive system. Specifically engineered for general-purpose motor control applications, this module supports rated output power of 1.1 kW (1.5 HP) and is ideal for small-scale automation systems including pumps, fans, conveyor belts, and HVAC components.

Designed to operate on 3-phase input voltage from 380 to 480 V AC (±10%) at a frequency of 47–63 Hz, this power module delivers an output current of approximately 2.3 A, ensuring precise control of standard induction motors. With an output frequency range from 0 to 650 Hz, it offers reliable speed and torque control over a wide variety of motor types and load conditions.

An integrated braking chopper enables the unit to support dynamic braking when used with an external braking resistor—this is particularly useful for decelerating high-inertia loads efficiently and safely. Cooling is achieved through a built-in internal fan, ensuring consistent thermal management under continuous duty.

The protection class is IP20, making it suitable for installation inside electrical control panels or enclosures. The vertical mounting style makes integration into space-constrained environments simple and effective. The module has a compact footprint, with approximate dimensions of 73 mm (W) x 225 mm (H) x 180 mm (D), and a weight of just 2.5 to 3 kg, allowing it to fit neatly within most industrial cabinets.

As part of the SINAMICS G120 family, the 6SL3210-5DE12-4UA0 is compatible with a variety of Siemens control units (such as CU240E-2, CU250S-2, and others), enabling advanced control features, communication via PROFINET or PROFIBUS, and integration into the TIA Portal through SINAMICS Startdrive or STARTER software.

Key Highlights:

• Rated Power Output: 1.1 kW (1.5 HP)

• Rated Output Current: ~2.3 A

• Input Voltage: 3-phase, 380–480 V AC ±10%

• Output Frequency: 0–650 Hz

• Cooling: Internal fan (air-cooled)

• Braking Chopper: Integrated, external resistor required

• Mounting: Vertical panel mount

• Protection Class: IP20

• Dimensions: 73 mm × 225 mm × 180 mm

• Weight: Approx. 2.5–3 kg

At Anadi Automation, we supply and support Siemens SINAMICS G120 drive systems with expert guidance, reliable service, and fast shipping for all your automation needs.
