Technical specifications for E84AVHCE2224SBO
Lenze E84AVHCE2224SB0 – Advanced Frequency Inverter Drive from the 8400 HighLine Series
The Lenze E84AVHCE2224SB0 is a high-performance frequency inverter drive from the renowned 8400 HighLine Installation series, designed to deliver precise motor control combined with enhanced safety and energy efficiency for industrial automation applications. This robust drive caters to demanding environments where reliability, control accuracy, and operator safety are paramount.
With a rated power output of 2.2 kW (3.0 HP), the E84AVHCE2224SB0 efficiently controls three-phase motors operating within the industrial voltage range of 400 to 500 V AC. The device supports an output frequency range of 0 to 599 Hz, allowing for flexible motor speed adjustments suitable for a wide array of applications, including conveyors, pumps, compressors, and machine tools. This extensive frequency range enables fine-tuned speed regulation, contributing to optimized process performance and reduced energy consumption.
A notable feature of this inverter drive is its integrated Safe Torque Off (STO) function, which complies with international safety standards. The STO functionality ensures immediate and reliable deactivation of motor torque without disconnecting power supply, significantly enhancing machine safety and operator protection during maintenance or emergency stop scenarios. This built-in safety mechanism reduces the need for external safety components, streamlining system design and minimizing downtime.
The drive’s input configuration includes a 3-phase plus protective earth (3/PE) connection, providing stable power supply and grounding for safe operation in industrial settings. Designed with flexibility in mind, the E84AVHCE2224SB0 supports seamless integration into existing automation networks and control systems, facilitating both new installations and retrofits.
Lenze’s 8400 HighLine series is known for its modular design and scalability, which allow this drive to be easily adapted to complex applications requiring multi-axis coordination or customized control strategies. The drive features sophisticated control algorithms that support vector control for superior dynamic performance and precise torque management, ensuring smooth acceleration and deceleration even under varying load conditions.
In addition to its performance capabilities, the E84AVHCE2224SB0 offers robust build quality with protections against overload, short circuits, and overheating, enhancing durability and operational reliability. The drive is designed for installation within control cabinets, typically rated with IP20 protection, safeguarding internal components from dust and accidental contact.
In summary, the Lenze E84AVHCE2224SB0 frequency inverter drive is a reliable, high-precision solution ideal for industrial applications requiring efficient motor control combined with integrated safety features. Its versatile performance, combined with advanced safety engineering, makes it an excellent choice for modern automation systems focusing on productivity, safety, and energy efficiency.
