Technical specifications for
E82EV551_2B
Lenze E82EV551_2B - Frequency Inverter (8200 Vector Series)
Product Overview
The Lenze E82EV551_2B is a vector-controlled frequency inverter from the 8200 Vector series, designed for precise motor speed and torque control in industrial applications. It is suitable for single-phase input and three-phase output, making it an ideal solution for various automation systems.
Technical Specifications
- Manufacturer: Lenze
- Model Number: E82EV551_2B
- Series: 8200 Vector
- Product Type: AC Frequency Inverter (VFD)
Electrical Specifications:
- Input Voltage: 1-Phase, 200-240V AC
- Input Frequency: 50/60 Hz
- Input Current: 3.9-6.0 A
- Output Voltage: 3-Phase, 0-230/240V AC
- Output Current: 3.0 A
- Power Rating: 0.55 kW (0.75 HP)
- Output Frequency: 0-650 Hz
Control & Features:
- Control Type: Vector Control / V/f (Voltage/Frequency) Control
- Communication Interfaces: CANopen, RS232, optional fieldbus modules (e.g., PROFIBUS)
- Enclosure Rating: IP20 (Suitable for control cabinet installation)
- Mounting Type: Panel-mounted
- Cooling System: Natural convection or forced cooling
- Protection Features: Overvoltage, Undervoltage, Overcurrent, Overload Protection
Environmental Conditions:
- Operating Temperature: 0°C to +40°C (Standard Conditions)
- Storage Temperature: -25°C to +70°C
- Relative Humidity: 5% to 95% (Non-condensing)
Physical Specifications:
- Weight: Approx. 0.45 kg
- Dimensions: Compact design for easy integration into control panels
Key Features & Benefits
✅ Vector Control for High-Performance Motor Control
✅ Compact and Panel-Mounted for Easy Integration
✅ Multiple Communication Options (CANopen, RS232, PROFIBUS)
✅ IP20 Rating for Cabinet Installation
✅ Advanced Protection Mechanisms for Enhanced Reliability
✅ Versatile Applications in Industrial Automation
