Technical specifications for
IC693MDL742D
The FANUC IC693MDL742D is a 16-point Discrete DC Output Module designed for the GE Fanuc Series 90-30 PLC platform. It provides 16 positive logic output points arranged in two isolated groups of eight outputs, allowing flexible wiring and reliable operation in industrial automation systems. The module operates with a nominal output voltage of 12 to 24 VDC and supports an operating voltage range of 5 to 30 VDC. Each output is capable of supplying up to 0.5 A, with a maximum current of 4 A per group. The module features electronic short-circuit protection and overload protection to enhance system reliability. It has fast response times of less than 0.5 ms for both ON and OFF transitions, ensuring precise control of field devices. The IC693MDL742D draws approximately 90 mA from the 5 V backplane bus and requires an external DC power supply for field outputs. It is compatible with GE Fanuc Series 90-30 PLC systems and is commonly used for controlling solenoid valves, relays, contactors, indicator lamps, and other DC output devices in industrial automation applications.
