Technical specifications for
IC693ALG442B
The FANUC IC693ALG442B is an 8-channel Analog Current/Voltage Input Module designed for the GE Fanuc Series 90-30 PLC platform. It provides eight single-ended analog input channels that can be individually configured for either voltage or current input signals, making it suitable for a wide range of industrial process control and automation applications. The module supports 0 to 10 VDC, -10 to +10 VDC, 0 to 20 mA, and 4 to 20 mA input ranges, depending on the selected configuration. It features 12-bit resolution for accurate signal conversion and offers high measurement precision for monitoring analog devices such as pressure transmitters, flow meters, temperature transmitters, and level sensors. The module is electrically isolated from the PLC backplane to improve system reliability and reduce electrical noise. It is installed directly into a GE Fanuc Series 90-30 PLC rack, draws power from the PLC backplane, and is fully compatible with Series 90-30 CPU systems for industrial automation and process control applications.
