Technical specifications for 8V1090.001-2
The 8BVI0110HCS0.000-1 is a servo drive from the B&R ACOPOSmulti Series, designed for high-performance industrial motion control applications. It delivers precise motor control with a single-axis inverter module for seamless machine integration.
1. Manufacturer & General Details
Model Number: 8BVI0110HCS0.000-1
Manufacturer: B&R Industrial Automation
Range: ACOPOSmulti Series
Product Type: Single-Axis Servo Drive (Inverter Module)
2. Dimensions & Weight
Dimensions (mm): 53.5 × 317 × 212
Weight: Approx. 2.4 kg
3. Electrical & Performance Specifications
Input Voltage: 750 VDC (Nominal DC Bus)
Continuous Power: 11.2 kW
Continuous Output Current: 15.1 A
Peak Output Current: 37.7 A
Output Frequency: Up to 598 Hz
4. Features & Application
Controller Type: Single-Axis Servo Inverter Module
Mounting: Cold Plate / Pass-Through Mounting
Protection: IP20
Application: Industrial motion control, CNC machines, robotics, packaging, material handling, and factory automation.
