★ ★ ★ ★ ★ Rated 5.0 with 6 Reviews

Part Number: TSXP57103M

Model Number: TSXP57103M

SCHNEIDER ELECTRIC TSXP57103M PROCESSOR

Schneider Electric TSXP57103M Processor CPU in stock. Advanced CPU for reliable automation control. Fast shipping available.

AVAILABLE IN STOCK

Part number: TSXP57103M
Brand: SCHNEIDER ELECTRIC
Product Type: PROCESSOR
Warranty: All the Parts has one year warranty *T&C
Stock Location: Nashik
In Stock Quantity:3

At Anadi Automation, we offer brand new equipment backed by the Original Manufacturers Warranty.

1.OEM warranty
2.Competitive pricing
3.Free quotes

* Equipment is subject to availability. Check Stock

Purchasing used parts can savings compared to buying brand new. At Anadi Automation, all our used spares come with a comprehensive 12-month warranty, ensuring your peace of mind. We strive to maximize your project cost savings.

1.Free 6 to 18 months warranty on the entire unit
2.Competitive pricing
3.Free quotes

* Equipment is subject to availability. Check Stock

Opting for refurbished items can lead to significant savings compared to purchasing brand new ones. At Anadi Automation, all our refurbished spare parts come with a comprehensive 12-month warranty, ensuring your peace of mind.

1.Free 12-month warranty covering the entire unit
2.Competitive pricing
3.Free quotes

* Equipment is subject to availability. Check Stock

If your TSXP57103M product has been damaged during use in the factory and you're seeking expert repair services, look no further. Contact us now, and we'll swiftly repair this product for you, helping you minimize costs. We offer quick repair services for the TSXP57103M product.

Sourcing your part

Global supplier of quality automation and control components

Service Exchange

Dispose of your old unit by exchanging it for a working part.

Repair

A comprehensive repair service for faulty equipment.

Alternative Names for TSXP57103M

T5XP57103M
TSXPS7103M
TSXP57I03M
TSXP571O3M

Technical specifications for TSXP57103M

Schneider Electric TSXP57103M – Modicon Premium PL7 Processor

The Schneider Electric TSXP57103M is a Modicon Premium Automation Platform Processor, designed for use with the PL7 Junior/Pro software. It features high I/O capacity, efficient power consumption, and rugged industrial performance.

1. General Information

Manufacturer: Schneider Electric
Model Number: TSXP57103M
Series: Modicon Premium Automation Platform
Product Type: Single-Format PL7 Processor
Software Compatibility: PL7 Junior / PL7 Pro
Module Format: Standard

2. Technical Specifications

Hardware & Capacity

Number of Slots: 16, 24, or 32
Discrete I/O Processor Capacity: 512 I/O
Analog I/O Processor Capacity: 24 I/O
Application-Specific Channels: 8

Electrical Specifications

Current Consumption: 440 mA at 5V DC

Environmental Ratings

Operating Altitude: 0 to 2000 meters
Pollution Degree: 2
Protective Treatment: TC
IP Degree of Protection: IP20 (Protection against solid objects but not liquids)

Physical Dimensions & Weight

Product Weight: 0.38 kg

3. Features & Benefits

✅ High I/O Capacity – Handles up to 512 discrete and 24 analog I/O
✅ Flexible Slot Configuration – Compatible with 16, 24, or 32-slot configurations
✅ Energy Efficient – Consumes only 440 mA at 5V DC
✅ Robust Performance – Protected with TC treatment for durability
✅ Wide Application Support – 8 dedicated application-specific channels

4. Applications

The Schneider Electric TSXP57103M PL7 Processor is widely used in:
Industrial Automation – PLC-based automation for manufacturing lines
Process Control – Efficient handling of industrial processes
Material Handling – Optimized control for conveyor and packaging systems
Building Management Systems (BMS) – Smart infrastructure automation
Energy & Utility Automation – Power grid and substation monitoring

5. Summary

The Schneider Electric TSXP57103M is a versatile and high-performance PLC processor, ideal for industrial automation and process control. With high I/O capacity, flexible slot configuration, and robust environmental protection, it offers a reliable and efficient control solution.

FAQ

Que1: What is the TSXP57103M used for? ▶

Ans: The TSXP57103M is a PL7 processor module designed for use in the Modicon Premium Automation Platform for industrial automation applications

Que2: Which software is compatible with the TSXP57103M? ▶

Ans: It is compatible with PL7 Junior and PL7 Pro software for programming and configuration.

Que3: How many slots does the TSXP57103M support? ▶

Ans: It supports configurations with 16, 24, or 32 slots.

Que4: What is the maximum I/O capacity of this processor? ▶

Ans: Discrete I/O: 512 I/O points
Analog I/O: 24 I/O points

Que5: How many application-specific channels does it support? ▶

Ans: The processor supports up to 8 application-specific channels.

Que6: What is the power consumption of the TSXP57103M? ▶

Ans: It consumes 440 mA at 5V DC.

Que7: What is the format of the TSXP57103M module? ▶

Ans: It comes in a standard module format.

Que8: What is the weight of the TSXP57103M? ▶

Ans: The module weighs 0.38 kg.
