Technical specifications for
25B-D010N104
Allen Bradley VFD CAT 25B-D010N104
The Allen-Bradley 25B-D010N104 is a PowerFlex 525 Variable Frequency Drive (VFD), designed for high-performance and flexibility in motor control applications. It supports an input voltage range of 323-528V AC, 3-phase, and a maximum motor output of 10.5 A, delivering up to 4.0 kW (5.0 HP) for both normal and heavy-duty usage. The built-in Ethernet/IP communication port provides seamless integration with modern industrial networks, while optional communication protocols like Dual Ethernet I/P, DeviceNet, and ProfiBus DP enhance connectivity options.
This VFD features a panel or DIN rail mounting option, with a compact enclosure rated at IP20 / NEMA UL Type Open, ensuring protection against solid objects but not liquids. It includes one analog input (0-10VDC / 0-20mA) for control flexibility. The drive provides an output voltage range of 0-460V AC, with an input current requirement of 13.8 A and output current of 10.5 A, ensuring robust power delivery.
Belonging to the PowerFlex 525 series, this adjustable frequency AC drive is part of the PowerFlex 40P family, and is designed to control the speed of AC motors with precision. It includes a standard interface module, comes in Frame Size B, and has no EMC filtering, making it suitable for general-purpose use. The VFD supports Ethernet/IP and RS-485 communications, further enhancing its versatility in automation systems. Measuring 87 x 180 x 172 mm and weighing 1.6 kg, it is compact and easy to install. This module helps in easy identification and procurement within the Allen-Bradley product lineup.
