Part Number: 1769-L35E

Model Number: 1769-L35E

ALLEN BRADLEY 1769-L35E CompactLogix Controllers

Name: 1769-L35E
Brand: ALLEN BRADLEY
Rating: 5 (5 reviews)

1769-L35E: Allen Bradley PLC CompactLogix controller available in stock. Offers advanced features for industrial automation, including built-in Ethernet/IP connectivity.

Check Availability

Part number: 1769-L35E
Brand: ALLEN BRADLEY
Product Type: CompactLogix Controllers
Warranty: A one-year warranty is provided by Anadi Automation. [Terms and Conditions apply]
Stock Location: Nashik, India
In Stock Quantity: Unit
Note: We are an independent supplier of ALLEN BRADLEY parts and are not an authorized distributor.

At Anadi Automation, we offer brand new CompactLogix Controllers equipment sourced from trusted suppliers.
Why Choose Us:

1.High-quality genuine products
2.Free quotes available

All products are subject to availability. Please check stock with our team.

Save More with Quality Used Parts
Purchasing used parts can offer significant savings compared to buying brand-new equipment.

At Anadi Automation, all our used spare parts come with a comprehensive 12-month warranty provided by us, giving you complete peace of mind. We are committed to helping you maximize your project’s cost efficiency.

Note:All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but does not include coverage by the original manufacturer

Save More with Refurbished Parts Opting for refurbished items can lead to significant savings compared to purchasing brand-new ones.

At Anadi Automation, all our refurbished spare parts come with a comprehensive 12-month warranty provided by us, ensuring your peace of mind.

Why Choose Anadi Automation:
1.12-month warranty by Anadi Automation
2.Free quotes with fast response times
3.Equipment is subject to availability. Please check stock with our team.

Note:All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but does not include coverage by the original manufacturer

1769-L35ERepair Services If your ALLEN BRADLEY 1769-L35E module has been damaged during factory use, we are here to help.

At Anadi Automation, we specialize in fast, reliable repairs to help you minimize downtime and reduce costs.

Contact us today for expert 1769-L35E repair services and get your operations back on track quickly!

Note:All repairs are handled by Anadi Automation with a warranty provided by us. This warranty does not come from Manufacturer, and we are not affiliated with any brands in providing this warranty.

Sourcing your part

Global supplier of quality automation and control components

Service Exchange

Dispose of your old unit by exchanging it for a working part.

Repair

A comprehensive repair service for faulty equipment.

Alternative Names for 1769-L35E

1769L35E
1769 L35E
I769-L35E
17G9-L35E
1769-L3SE

Technical specifications for 1769-L35E

Allen-Bradley 1769-L35E – CompactLogix Controller

Product Overview

The Allen-Bradley 1769-L35E is a CompactLogix Processor Module designed for mid-to-large automation systems. With EtherNet/IP and RS-232 connectivity, it offers high-performance control, real-time data exchange, and seamless integration into industrial networks.

Technical Specifications

✔ Manufacturer: Rockwell Automation / Allen-Bradley
✔ Brand: Allen-Bradley
✔ Part Number: 1769-L35E
✔ Product Line: CompactLogix
✔ Product Type: CompactLogix Controller
✔ Module Type: Processor Module
✔ User Memory: 1.5MB
✔ Non-Volatile Memory: 1784-CF128

Communication & Networking

✔ Communication Ports: 1x RS232, 1x Ethernet
✔ Supported Protocols: EtherNet/IP, DH485, DF1, ASCII
✔ Ethernet Communication Cable: Cat5 / Cat6 Ethernet Cable

I/O & Expansion Capabilities

✔ Maximum I/O Modules Supported: 30 Modules
✔ Maximum I/O Banks Supported: 3 Banks
✔ Power Supply Distance Rating: 4

Electrical & Wiring Details

✔ Battery Type: 1769-BA
✔ Programming Cable: 1747-CP3 / 1756-CP3
✔ Wire Type: Copper - 90°C Rated
✔ Wire Size (Solid): 22 to 14 AWG
✔ Wire Size (Stranded): 22 to 16 AWG

Operating Conditions

✔ Operating Temperature: 0° to +60°C (+32° to +140°F)
✔ Storage Temperature: -40° to +85°C (-40° to +185°F)
✔ Vibration Resistance: Operating: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak
✔ Frequency: 10 to 500 Hz
✔ Mounting Torque: 1.1 to 1.8 N-m

Physical & Shipping Details

✔ Shipping Dimensions: 8 x 8 x 5 inches

Key Features & Benefits

✅ EtherNet/IP Connectivity – Enables real-time industrial networking, remote access, and data logging.
✅ High I/O Capacity – Supports up to 30 I/O modules, ideal for large automation systems.
✅ Expandable & Modular Design – Compatible with CompactLogix I/O and power supplies.
✅ Multi-Language Programming – Compatible with ladder logic, structured text, function block, and SFC.
✅ Industrial-Grade Reliability – Designed to withstand vibration, high temperatures, and industrial environments.

FAQ

Que1: What is the 1769-L35E CompactLogix controller used for? ▶

Ans: The 1769-L35E is a programmable automation controller (PAC) used for machine control, process automation, and industrial applications requiring EtherNet/IP communication.

Que2: What communication ports are available on the 1769-L35E? ▶

Ans: 1 Ethernet/IP port (supports EtherNet/IP communication)

1 RS232 serial port (supports DH485, DF1, ASCII protocols)

Que3: What is the memory capacity of the 1769-L35E? ▶

Ans: User memory: 1.5 MB

Non-volatile memory: 1784-CF128 CompactFlash card

Que4: How many I/O modules can be connected to the 1769-L35E? ▶

Ans: Maximum I/O modules supported: 30

Maximum I/O banks: 3 banks

Que5: What power supply and battery are compatible with the 1769-L35E? ▶

Ans: Power supply distance rating: 4 modules

Battery backup: 1769-BA

Que6: What programming cables are required for the 1769-L35E? ▶

Ans: RS232 Programming Cable: 1747-CP3 / 1756-CP3

Ethernet Communication Cable: Cat5 / Cat6 Ethernet cable

Que7: What is the operating temperature range of the 1769-L35E? ▶

Ans: 0°C to +60°C (32°F to 140°F)

Que8: What are the vibration and shock resistance specifications? ▶

Ans: Vibration resistance: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak

Que9: What wire types and sizes are supported? ▶

Ans: Solid wire: 22 to 14 AWG

Stranded wire: 22 to 16 AWG

Copper wire rated at 90°C

Que10: What are the physical dimensions and weight of the 1769-L35E? ▶

Ans: Shipping Dimensions: 8 x 8 x 5 inches
