Model Number 1769-ASCII

ALLEN BRADLEY 1769-ASCII CompactLogix

Name: 1769-ASCII
Brand: ALLEN BRADLEY
Rating: 5 (5 reviews)

1769-ASCII: Allen Bradley PLC module currently in stock. Provides ASCII communication capabilities for CompactLogix systems, enhancing data handling and connectivity.

Check Availability

Call Us WhatsApp Email Get Quote

Choose Any Secure Payment options

Part number: 1769-ASCII
Brand: ALLEN BRADLEY
Product Type: CompactLogix
Warranty: A one-year warranty is provided by Anadi Automation. [Terms and Conditions apply]
Stock Location: Nashik, India
In Stock Quantity: 2 Unit
Note: We are an independent supplier of ALLEN BRADLEY parts and are not an authorized distributor.

At Anadi Automation, we offer brand new CompactLogix equipment sourced from trusted suppliers.

Why Choose Us:

1. High-quality genuine products
2. Free quotes available

All products are subject to availability. Please check stock with our team.

Save More with Quality Used Parts

Purchasing used parts can offer significant savings compared to buying brand-new equipment.

At Anadi Automation, all our used spare parts come with a comprehensive 12-month warranty provided by us, giving you complete peace of mind.

Note: All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but does not include coverage by the original manufacturer.

Save More with Refurbished Parts

Opting for refurbished items can lead to significant savings.

At Anadi Automation, all our refurbished spare parts come with a comprehensive 12-month warranty.

Why Choose Anadi Automation:
1. 12-month warranty
2. Free quotes with fast response
3. Subject to availability. Please check stock with our team.

Note: All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but not original manufacturer coverage.

1769-ASCII Repair Services

If your ALLEN BRADLEY 1769-ASCII module has been damaged, we can help.

We specialize in fast, reliable repairs to minimize downtime.

Contact us today for expert repair services.

Note: All repairs are handled by Anadi Automation with warranty provided by us. Not from the original manufacturer.

Discover Our Unique Services

Sourcing your part

Global supplier of quality automation and control components.

Service Exchange

Dispose of your old unit by exchanging it for a working part.

Repair

A comprehensive repair service for faulty equipment.

Alternative Names for 1769-ASCII

1769ASCII

1769 ASCII

I769-ASCII

17G9-ASCII

1769-A5CII

1769-ASC11

Technical specifications for 1769-ASCII

Allen-Bradley 1769-ASCII - ASCII Communication Module

Product Overview

The Allen-Bradley 1769-ASCII is a CompactLogix specialty module designed for serial ASCII communication. It provides a flexible interface for integrating barcode scanners, printers, and other ASCII-based devices into PLC systems.

Technical Specifications

✔ Manufacturer: Rockwell Automation
✔ Brand: Allen-Bradley
✔ Product Line: CompactLogix
✔ Product Type: Specialty Communication Module
✔ Part Number: 1769-ASCII
✔ Series: A and B

Power & Electrical Specifications

✔ Power Consumption: 33.6 Watts
✔ Power Dissipation (Max): 2.13 Watts
✔ Thermal Dissipation: 7.3 BTU/hr
✔ Backplane Current Draw: 1.4 Amps at 24V DC
✔ Isolation Voltage: 30V Continuous

Communication Capabilities

✔ Module Type: ASCII Communication Interface
✔ Communication Protocols: RS-232, RS-422, RS-485
✔ Number of Ports: 2 Full Duplex (RS-232, RS-422), 2 Half Duplex (RS-485)
✔ Handshaking: RTS/CTS Hardware Handshaking Enabled
✔ Input Words: 108
✔ Configuration Words: 31

Physical & Environmental Specifications

✔ Operating Temperature: 0°C to 62°C (32°F to 140°F)
✔ CompactLogix Power Supply Distance Rating: 4
✔ Shipping Weight: 2 lbs (0.91 kg)
✔ Shipping Dimensions: 8 x 8 x 5 inches (203 x 203 x 127 mm)

Key Features & Benefits

✅ Seamless ASCII Communication – Easily connects barcode scanners, printers, and serial devices.
✅ Multi-Protocol Support – Works with RS-232, RS-422, and RS-485 communication standards.
✅ Reliable Handshaking – RTS/CTS hardware handshaking ensures smooth and efficient data exchange.
✅ Low Power Consumption – Operates with minimal heat generation for enhanced system reliability.
✅ Compact Design – Ideal for tight control panel installations in industrial automation.

FAQ

Que1: What is the Allen-Bradley 1769-ASCII module used for? ▶

Ans: The 1769-ASCII is a Compact I/O specialty module that enables ASCII communication between Allen-Bradley CompactLogix and MicroLogix 1500 PLCs and ASCII-based serial devices.

Que2: What types of serial communication does the module support? ▶

Ans: The module supports:

2 Full-Duplex channels (RS-232, RS-422)

2 Half-Duplex channels (RS-485)

Que3: What is the isolation voltage rating? ▶

Ans: The 1769-ASCII has an isolation voltage of 30V (continuous) for safety in industrial applications.

Que4: What is the power consumption and dissipation of the module? ▶

Ans: Power Consumption: 33.6 Watts

Power Dissipation: 7.5 Watts

Thermal Dissipation: 7.3 BTU/hr.

Que5: What is the backplane current draw of the module? ▶

Ans: The 1769-ASCII draws 1.4 Amps at 24V DC from the backplane.

Que6: What is the power supply distance rating? ▶

Ans: The module must be placed within 4 modules from the power supply for proper operation.

Que7: Does the 1769-ASCII support hardware handshaking? ▶

Ans: Yes, it supports RTS/CTS hardware handshaking for better serial communication control.
