ALLEN BRADLEY 1764-24BWA MicroLogix Controller

1764-24BWA: Allen Bradley MicroLogix 1500 PLC module. Offers reliable performance and versatile control capabilities for industrial automation applications.

Check Availability

Part number: 1764-24BWA
Brand: ALLEN BRADLEY
Product Type: MicroLogix Controller
Warranty: A one-year warranty is provided by Anadi Automation. [Terms and Conditions apply]
Stock Location: Nashik, India
In Stock Quantity: Unit
Note: We are an independent supplier of ALLEN BRADLEY parts and are not an authorized distributor.

At Anadi Automation, we offer brand new MicroLogix Controller equipment sourced from trusted suppliers.
Why Choose Us:

1.High-quality genuine products
2.Free quotes available

All products are subject to availability. Please check stock with our team.

Save More with Quality Used Parts
Purchasing used parts can offer significant savings compared to buying brand-new equipment.

At Anadi Automation, all our used spare parts come with a comprehensive 12-month warranty provided by us, giving you complete peace of mind. We are committed to helping you maximize your project’s cost efficiency.

Note:All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but does not include coverage by the original manufacturer

Save More with Refurbished Parts Opting for refurbished items can lead to significant savings compared to purchasing brand-new ones.

At Anadi Automation, all our refurbished spare parts come with a comprehensive 12-month warranty provided by us, ensuring your peace of mind.

Why Choose Anadi Automation:
1.12-month warranty by Anadi Automation
2.Free quotes with fast response times
3.Equipment is subject to availability. Please check stock with our team.

Note:All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but does not include coverage by the original manufacturer

1764-24BWARepair Services If your ALLEN BRADLEY 1764-24BWA module has been damaged during factory use, we are here to help.

At Anadi Automation, we specialize in fast, reliable repairs to help you minimize downtime and reduce costs.

Contact us today for expert 1764-24BWA repair services and get your operations back on track quickly!

Note:All repairs are handled by Anadi Automation with a warranty provided by us. This warranty does not come from Manufacturer, and we are not affiliated with any brands in providing this warranty.

Sourcing your part

Global supplier of quality automation and control components

Service Exchange

Dispose of your old unit by exchanging it for a working part.

Repair

A comprehensive repair service for faulty equipment.

Alternative Names for 1764-24BWA

176424BWA
I764-24BWA
17G4-24BWA
1764-Z4BWA
1764-248WA

Technical specifications for 1764-24BWA

Allen-Bradley 1764-24BWA – MicroLogix 1500 Base Unit

The Allen-Bradley 1764-24BWA is a MicroLogix 1500 base controller, designed for compact and efficient industrial automation applications. It features 12 inputs and 12 outputs, supports up to 512 expanded I/O points, and operates on 85-265V AC power.

1. General Information

Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Model Number: 1764-24BWA
Series: MicroLogix 1500
Module Type: Base Unit / Controller
Function: Base Controller
Mounting: Horizontal
Compatible Processors: 1764-LSP and 1764-LRP
Memory Modules Supported: 1764-MM1 to 1764-MM4
Real-Time Clock Compatibility: 1764-RTC or 1764-MM1RTC

2. Technical Specifications

Power & Electrical Ratings

Power Supply Voltage: 85-265V AC
Line Power: 85-265 Volts AC

Inputs & Outputs

Total I/O Rating: 12 Inputs / 12 Outputs
Input Voltage: 24V DC
Input Circuit Type: 24V DC Sink/Source
Output Type: Relay Port
Output Voltage: 24-125V DC / 120-240V AC
Maximum Expanded I/O Count: 512 I/O
Operating Frequency: 0 to 20 kHz

Communication & Interfaces

Ports: RS-232 Serial Ports

Physical Dimensions & Environmental Ratings

Dimensions: 5.43 x 6.62 x 3.43 inches
Operating Temperature: 32°F to 131°F (0°C to 55°C)

3. Features & Benefits

✅ Compact & Versatile – Ideal for small to mid-range automation systems
✅ Expandable I/O – Supports up to 512 I/O modules for future scalability
✅ Reliable Communication – RS-232 serial ports for seamless connectivity
✅ Dual Processor Compatibility – Works with both 1764-LSP & 1764-LRP processors
✅ Wide Input & Output Support – Handles AC and DC voltages for various applications
✅ Real-Time Clock Support – Ensures precise time-based control with 1764-RTC module
✅ Memory Module Compatibility – Supports 1764-MM1 to 1764-MM4 for enhanced storage

4. Applications

The Allen-Bradley 1764-24BWA MicroLogix 1500 Base Unit is perfect for:
Machine Control – Reliable automation for small manufacturing systems
Process Automation – Efficient handling of industrial processes
SCADA & Data Acquisition – Integrates easily into supervisory control systems
Conveyor Systems – Ideal for material handling applications
HVAC & Building Automation – Optimized control for energy-efficient operation

5. Summary

The Allen-Bradley 1764-24BWA MicroLogix 1500 Base Unit is a versatile, scalable, and compact industrial controller, designed for small to mid-range automation applications. With expandable I/O, wide input/output voltage support, and RS-232 communication, it provides a reliable and cost-effective control solution.

FAQ

Que1: What is the function of the 1764-24BWA module? ▶

Ans: The 1764-24BWA is a Base Controller Unit for the Allen-Bradley MicroLogix 1500 series, providing power and I/O connections for various industrial automation applications.

Que2: How many I/O channels does this unit support? ▶

Ans: This base unit has 12 digital inputs and 12 digital outputs, supporting a total of 24 I/O points.

Que3: What type of input and output voltage does it support? ▶

Ans: Input Voltage: 24V DC (sink/source)
Output Voltage: 24-125V DC or 120-240V AC

Que4: What is the maximum expanded I/O capacity of this base unit? ▶

Ans: The 1764-24BWA can be expanded up to 512 I/O points using additional expansion modules.

Que5: Which processors are compatible with the 1764-24BWA? ▶

Ans: It supports 1764-LSP and 1764-LRP processors.

Que6: What communication ports are available? ▶

Ans: The unit features RS-232 Serial Ports for communication and programming.

Que7: Does this unit support memory expansion? ▶

Ans: Yes, it is compatible with 1764-MM1 to 1764-MM4 memory modules for program storage and data retention.

Que8: What are the physical dimensions of the 1764-24BWA? ▶

Ans: The unit measures 5.43 x 6.62 x 3.43 inches, allowing horizontal mounting.
