Technical specifications for
PM582
ABB PM582 - Programmable Logic Controller (PLC)
Product Overview
The ABB PM582 is a Programmable Logic Controller (PLC) designed for industrial automation applications. It features a compact design, high-speed processing, and reliable performance, making it suitable for factory automation, process control, and machine automation.
Technical Specifications
✔ Manufacturer: ABB
✔ Extended Product Type: PM582
✔ Product Type: Programmable Logic Controller (PLC)
Electrical & Processing Specifications
✔ Rated Voltage (Ur): 24V DC
✔ Supply Voltage Range: 20.4V – 28.8V DC
✔ Controller Processing Time: 0.00005 ms
Memory & Storage
✔ Total Memory Size: 928 kB
✔ User Program Memory: 512 kB
✔ User Data Memory: 416 kB
✔ Memory Type: RAM
I/O & Expandability
✔ Number of Digital Configurable I/Os: 0
✔ Expansion: Supports additional I/O modules (sold separately)
Physical Dimensions & Protection
✔ Degree of Protection: IP20
✔ Product Net Width: 67.5 mm
✔ Product Net Height: 76 mm
✔ Product Net Depth / Length: 62 mm
✔ Product Net Weight: 0.134 kg
Packaging Dimensions
✔ Package Level 1 Width: 71 mm
✔ Package Level 1 Height: 72 mm
✔ Package Level 1 Depth / Length: 84 mm
✔ Gross Weight: 0.158 kg
Key Features & Benefits
✅ High-Speed Processing (0.00005 ms) – Ensures fast execution of logic operations.
✅ Compact & Lightweight Design – Fits in space-constrained control panels.
✅ Expandable I/O Modules – Allows for flexible system configuration.
✅ Industrial-Grade Reliability – Designed for harsh industrial environments with IP20 protection.
✅ Wide Voltage Tolerance (20.4V – 28.8V DC) – Provides stability in fluctuating power conditions.
