Model Number
1766-L32BXB
ALLEN BRADLEY 1766-L32BXB MicroLogix Controller
Get the Allen Bradley MicroLogix 1400 1766-L32BXB controller for advanced industrial automation. Features 32 I/O points, built-in Ethernet, and reliable performance.
Choose Any Secure Payment options
.jpeg)
.jpeg)
.jpeg)
Part number: 1766-L32BXB
Brand: ALLEN BRADLEY
Product Type: MicroLogix Controller
Warranty: A one-year warranty is provided by Anadi Automation. [Terms and Conditions apply]
Stock Location: Nashik, India
In Stock Quantity: Unit
Note: We are an independent supplier of ALLEN BRADLEY parts and are not an authorized distributor.
Brand: ALLEN BRADLEY
Product Type: MicroLogix Controller
Warranty: A one-year warranty is provided by Anadi Automation. [Terms and Conditions apply]
Stock Location: Nashik, India
In Stock Quantity: Unit
Note: We are an independent supplier of ALLEN BRADLEY parts and are not an authorized distributor.
At Anadi Automation, we offer brand new MicroLogix Controller equipment sourced from trusted suppliers.
Why Choose Us:
1. High-quality genuine products
2. Free quotes available
All products are subject to availability. Please check stock with our team.
Save More with Quality Used Parts
Purchasing used parts can offer significant savings compared to buying brand-new equipment.
At Anadi Automation, all our used spare parts come with a comprehensive 12-month warranty provided by us, giving you complete peace of mind.
Note: All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but does not include coverage by the original manufacturer.
Save More with Refurbished Parts
Opting for refurbished items can lead to significant savings.
At Anadi Automation, all our refurbished spare parts come with a comprehensive 12-month warranty.
Why Choose Anadi Automation:
1. 12-month warranty
2. Free quotes with fast response
3. Subject to availability. Please check stock with our team.
Note: All products, including refurbished and used items, come with a 12-month warranty provided directly by Anadi Automation. This warranty covers parts and labor, but not original manufacturer coverage.
1766-L32BXB Repair Services
If your ALLEN BRADLEY 1766-L32BXB module has been damaged, we can help.
We specialize in fast, reliable repairs to minimize downtime.
Contact us today for expert repair services.
Note: All repairs are handled by Anadi Automation with warranty provided by us. Not from the original manufacturer.
Service Exchange
Dispose of your old unit by exchanging it for a working part.
Repair
A comprehensive repair service for faulty equipment.
Alternative Names for 1766-L32BXB
- 1766L32BXB
- 1766 L32BXB
- I766-L32BXB
- 17GG-L32BXB
- 1766-L3ZBXB
- 1766-L328X8
Technical specifications for 1766-L32BXB
Allen Bradley Micrologix 1400 1766-L32BXB
The 1766-L32BXB is a high-performance MicroLogix 1400 controller from Allen-Bradley, part of Rockwell Automation’s MicroLogix family. Designed for flexible and reliable automation control, the 1766-L32BXB offers a powerful feature set ideal for small to mid-sized applications. This compact controller includes 32 I/O points, comprising (12) fast 24V DC inputs, (8) normal 24V DC inputs, (6) relay outputs, (3) fast 24V DC outputs, and (3) normal 24V DC outputs, delivering versatile digital control.
With 20 KB of memory, built-in real-time clock (RTC), and EtherNet/IP connectivity, the Allen Bradley 1766 L32BXB ensures efficient data handling and real-time communication. It also supports a wide range of protocols including DF1, ASCII, MODBUS RTU, DNP3, DH485 via serial ports and MODBUS TCP/IP, DNP3, Ethernet/IP over Ethernet.
Operating on 24V DC power, this controller consumes 7.5W without expansion and can handle inrush currents up to 15 A for 20 ms. Its dimensions are 90 x 180 x 87 mm and it supports panel or DIN rail mounting, offering installation flexibility. Though it lacks analog input range features, its robust discrete I/O and communication capabilities make the 1766 l32bxb a top choice for scalable automation projects.
FAQ
Que1: What is the total I/O count for this MicroLogix 1400 controller?
▶
Ans: The controller offers a total of 32 I/O points, consisting of digital and analog inputs and outputs.
Que2: What kind of digital inputs does the unit support?
▶
Ans: It includes 12 fast 24V DC inputs and 8 normal 24V DC inputs, designed for different signal response needs.
Que3: How many output types are available on the controller?
▶
Ans: There are 6 relay outputs, 3 fast 24V DC outputs, and 3 normal 24V DC outputs for flexible control.
Que4: Does this controller include analog inputs?
▶
Ans: Yes, it includes 2 analog inputs, although there is no analog input signal range specified for scaling.
Que5: What communication ports and protocols does it support?
▶
Ans: It supports RS232, RS485, and Ethernet ports and communicates via DF1, ASCII, Modbus RTU, DNP3, DH485, Ethernet/IP, and Modbus TCP/IP protocols.
Que6: What is the power supply and consumption specification?
▶
Ans: The controller runs on 24V DC, with a 50W max consumption, and 7.5W without 1762 expansion modules.
Que7: What are the key features of the Allen-Bradley 1766-L32BXB controller?
▶
Ans: This MicroLogix 1400 series controller comes with built-in RTC, multiple communication options, 20KB memory, and support for panel or DIN rail mounting.
